技術參數
圓盤粉碎機
Disc grinder
圓盤粉碎機體積小,噪音低,操作簡便,不用分篩,不用安裝;易清掃,無粉塵外溢;不污染環境,有利于操作人員健康,能連續工作,可將物料一次性破碎至80目以下。適用于地質、冶金、煤炭、建材、礦山、化工、選礦、科研等行業化驗室、實驗室的破碎工作。
Disc grinder has the advantages of small volume, low noise, easy to operate, without screening, no installation; easy to clean, no dust spillover; does not pollute the environment, conducive to the health of operating personnel, can work continuously, the materials can be broken into 80 orders below one-time. Crushing is applicable to geological, metallurgical, coal, building materials, chemical industry, mining, mineral processing, industry and scientific research, laboratory of laboratory.
型 號:ф150
磨盤直徑:150
給料較大料度:2mm
出料粒度:0.1mm
生產率:20kg/h
主軸轉速:778r/min
電動機型號:Y909-4
轉 速:940r/min
功 率:1.5kw
外形尺寸:690×465×400mm
重 量:110kg
磨 盤:高錳鋼
型號
Model |
單位
Unit |
φ150 |
φ175 |
φ200 |
φ250 |
φ300 |
磨盤直徑
Grinding diameter |
mm |
150 |
175 |
200 |
250 |
300 |
進料粒度
Feed particle size |
mm |
≤2 |
≤3 |
≤6 |
≤8 |
≤10 |
出料粒度
The grain size |
mm |
0.1 |
0.1 |
0.2 |
0.3 |
0.4 |
生產量
Output |
kg/h |
20 |
25 |
60 |
80 |
100 |
電機功率
Motor power |
kw |
1.5 |
1.5 |
2.2 |
3 |
4 |
外形尺寸
Size and shape |
mm |
800×500×520 |
800×500×520 |
1000×550×650 |
1000×550×650 |
1000×550×750 |
重量
Weight |
kg |
110 |
150 |
180 |
190 |
210 |
南昌市恒順化驗設備制造有限公司專業生產實驗室圓盤粉碎機,質量保證,購設備6個月內有質量問題包退、包換,并免費保修一年,包運費(木箱包裝),含增值稅13%,歡迎咨詢洽談。
